This swivel is designed for a right hand drive (UK/Ireland) original double passenger seat.

Got a double passenger seat in your Renault Trafic 3rd Gen X82 (2014 - present) ? Now you can make it spin around to face the back of your campervan.

Transform the living space in your van without losing all the benefits of the bench seat in the front.

The swivel mechanism is very different from normal single swivels. It uses a cunning slide and swivel approach, so you will need to open the side door to allow the full range of movement. The seat is held securely in position while driving by 4 x specially engineered locking bolts.

Fitting

Fitting is even easier than the T5 model and only takes about 30 minutes. As these vehicles come with a seat-belt pre-tensioner system, you do need to unplug one connection under the seat before turning (it only takes a few seconds). This needs to be plugged back in before driving off, but your dashboard warning light will remind you if you forget.

Safety Certification

This swivel is not TÜV certified, but this does not mean that it cannot be approved for use in your country.

Approval process in the EU

Each country applies different rules across similar standards. The product has been tested to specifications recognised in the EU, but each country follows their own rules on how a vehicle might be approved. These rules are often applied quite differently from region to region, or even inspector to inspector. We recommend that before you make your purchase you contact the appropriate organisation in your location to establish what you require to successfully use this product.

STATUS Certification

The double Seat Swivel has passed seat belt anchorage safety tests conducted by STATUS (The Specialist Testing Facility at Manchester Met Uni) using a pull test on a specialist test rig to EC Directive 76/115/EEC as amended by 2005/41/EEC. The certificate can be downloaded here: X82/X83 Double Swivel STATUS Certificate

Features

Self-levelling design to counteract sloping cab floor, making rotated seat actually comfortable to sit on!
High density, low friction 'glide layer' for ease of rotation.
External locking screws

Compatibility

This product is fully compatible with all van models in the X82/X83 range:

Opel / Vauxhall Vivaro X83 2001-2014 (2nd Generation)
Opel / Vauxhall Vivaro X82 2014-2018 (3rd Generation)
Renault Trafic X83 2001-2014 (2nd Generation)
Renault Trafic X82 2014+ (3rd Generation)
Nissan Primastar X83 2001-2014
Nissan NV300 X82 2014+
Mitsubishi Express X82 2014+
Fiat Talento X82 2016 - 2022

Designed for original seats
Works with or without a driver seat swivel
Compatible with heated seats or built-in passenger airbags (Note: it is necessary to disconnect/reconnect these connections while rotating the seat)

Product Specification

Height Increase of your front seat with swivel fitted: 35mm

Includes

All nuts and bolts supplied
